    Picoscope 6000 series

    It has all, high bandwidth, high sampling rate and more buffer memory than any other oscilloscope. Giving the user ultimate performance.

    4 channels

    350-500 MHz bandwidth
    5 GS/s real-time sampling
    Up to 1 GS memory
    Integrated function and
    arbitrary waveform generator

    Oscilloscope — Vertical
    Model PicoScope 6402 PicoScope 6403 PicoScope 6404
    Bandwidth 350 MHz  (-3 dB) with TA101 probes or on 50 Ω  setting; switchable 20 MHz  bandwidth limiters 500 MHz  (-3 dB) with TA133 probes or on 50 Ω  setting; switchable 25 MHz  bandwidth limiters
    Rise time (10% to 90%, calculated) 1 ns  700 ps
    Input channels 4
    Vertical resolution 8 bits
    Enhanced vertical resolution 12 bits
    DC accuracy ±3%
    Input sensitivity 10 mV/div to 4 V/div at x1 zoom
    Input characteristics 1 MΩ  in parallel with 15 pF  (AC or DC) or 50 Ω  (DC only) 1 MΩ  in parallel with 11 pF  (AC or DC) or 50 Ω  (DC only)
    Input type Single–ended, BNC connector
    Input coupling Software selectable AC/DC
    Input ranges (full scale) ±50 mV  to ±20 V  in 9 ranges (up to ±5 V  when 50 Ω  input selected)
    Input offset (position) adjustment
    50 mV  to 200 mV
    500 mV
    1 V
    2 V
    5 V
    10 V
    20 V
    ±0.5 V
    ±2.5 V
    ±2.5 V
    ±2.5 V
    ±20 V  (50 Ω: ±0.5 V)
    ±20 V
    ±20 V
    ±2 V
    ±10 V  (50 Ω: ±5 V)
    ±10 V  (50 Ω: ±4.5 V)
    ±10 V  (50 Ω: ±3.5 V)
    ±35 V  (50 Ω: ±0.5 V)
    ±30 V
    ±20 V
    Overload protection ±100 V to ground (1 MΩ inputs), 5.5 V RMS (50 Ω inputs)

    Oscilloscope — Horizontal
    Maximum sampling rate (single shot)
    1 channel in use
    2 channels in use
    3 or 4 channels in use
    5 GS/s
    2.5 GS/s
    1.25 GS/s
    Maximum sampling rate (repetitive signals) 50 GS/s
    Maximum sampling rate
    (continuous streaming mode)    		 1 MS/s  using PicoScope
    13 MS/s  using the supplied SDK (PC dependent)
    Buffer memory
    (shared between active channels)
    32 MS
    1 GS
    Waveform buffer Up to 10,000 waveforms
    Timebase ranges
    Real–time
    ETS
    1 ns/div to 200 s/div
    1 ns/div to 200 s/div
    10 ns/div to 200 s/div
    1 ns/div to 200 s/div
    Timebase accuracy 5 ppm
